tianma_tm070jdhg30_E-070-1280X0800-L500-T_hdmi

7" 1280x800 Industrial EMBEDDED HDMI TOUCH DISPLAY

INDUSTRIAL GLASS with superior viewing angle SFT Normally Black TFT panels. Added to this are Long Life Backlights HDMI Industrial, Wide Operating Temperatures and USB HID PCT Touch. This represents the state of the art for technology and design benefits for your next project! We couple this with "INDUSTRIAL BY DESIGN" architecture for extended form factor support!

tm070jdh30

400 cd/m2 SUNLIGHT READABLE 1280 x 800 SFT Normally Black HDMI PCT Touch

A TRUE Industrial by Design Extended Temperature (-20 to 70C) HD Ultra Wide Viewing Angle, PCT embedded display.

Outline Size(mm)	180.44x125.86x17.70
Active Area (mm)	149.76x93.60
Resolution	1280x800
Brightness (cd/m2)	400 (360*)
LED Lifetime (HRS)	30,000
Display Mode	SFT Normally Black
Viewing Angle (degrees)	88,88,88,88
TFT Interface	HDMI
Touch	PCT USB HID
Operating (C)	-20 to 85
Operating (V)	5.0

E-070-1280X0800-L500-T PCT

E-070-1280X0800-L500

Our Valued Suppliers

Focused on the Industrial Embedded HMI market:

Display PARTNERS:

PIXELNEXT focuses on bringing world class TFT Displays, Touch Screens and the Electronics that Drives them to the industrial display industry. We target Instrument Grade or Industrial Grade displays using our "Industrial by Design" core principles and industrially adopted interfaces such as HDMI, MIPI and USB HID. We are dedicated to being your PARTNER, not your vendor.

Tianma Microelectronics Co. Ltd. has 30 years of GLOBAL market display history. They support applications including automotive, instrumentation, industrial, medical, avionic, marine, KIOSK and POS. Tianma is a leader of small to medium size displays in technology, quality and long-term support for customers around the world.
